Frozen AC Evaporator Coil (Troubleshooting & Fixes)

    Seeing ice on your AC unit? Your AC probably isn't cooling right. A veteran tech explains why your evaporator coil is frozen and how to fix it fast.

    DIY Fix: $5–$20
    Pro Help: $150–$500
    Time: 15–120 min

    Quick Answer

    Okay, so here's the quick version. Your AC's turned into a block of ice because it can’t breathe. Nine times out of ten, it’s a filthy air filter blocking airflow. First thing you do is TURN THE AC OFF at the thermostat, but switch the FAN to ON. This will thaw the ice safely. Don't you dare go chipping at it. While it's thawing, go check your filter. If it looks like a fuzzy gray carpet, replace it. That might be your only problem. If it freezes up again after that, you're likely low on refrigerant, and that means you've got a leak. That's a pro call, period.

    Frozen AC Evaporator Coil (Troubleshooting & Fixes) visual diagram
    Visual guide for diagnosing key fob issues

    Common Symptoms

    AC not cooling effectively or blowing warm air
    Visible ice buildup on the indoor AC unit or refrigerant lines
    Reduced airflow from vents
    Water leaks around the indoor unit as ice melts
    System running continuously without reaching the desired temperature

    Possible Causes

    Restricted airflow: Most commonly caused by a dirty air filter, but also blocked return/supply vents or a dirty evaporator coil.
    Low refrigerant levels: A leak in the system causes pressure to drop, making the evaporator coil too cold and freezing moisture on its surface.
    Malfunctioning blower motor: If the blower fan isn't moving enough air due to a failed motor or capacitor, the coil won't absorb heat and can freeze.

    Step-by-Step Diagnosis

    1

    Step 1

    Turn the AC system from COOL to OFF at the thermostat.

    2

    Step 2

    Switch the fan setting from AUTO to ON to circulate air and melt the ice.

    3

    Step 3

    Inspect the air filter for dirt and replace it if it's clogged.

    4

    Step 4

    Check all supply and return vents in the house to ensure they are open and unobstructed.

    5

    Step 5

    Wait for the ice to melt completely before turning the AC back to COOL.

    6

    Step 6

    If the coil refreezes after these steps, it indicates a more serious problem like a refrigerant leak, and you should call a professional.

    Frozen AC Evaporator Coil (Troubleshooting & Fixes)
    Key fob troubleshooting and repair overview

    DIY vs Professional Costs

    Thawing the Coil & Replacing a Filter
    DIY$10-50
    Pro$75-150
    Time1-4 hours
    Cleaning a Lightly Dusted Evaporator Coil
    DIY$10-50
    Pro$200-500
    Time2-3 hours
    Refrigerant Leak Search & Recharge
    DIYNOT A DIY JOB
    Pro$350-1,000+
    Time2-5 hours
    Blower Motor & Capacitor Replacement
    DIY$50-300
    Pro$450-1,200+
    Time2-4 hours
    Evaporator Coil Replacement
    DIYNOT A DIY JOB
    Pro$1,500-4,000+
    Time4-8 hours

    When to Call a Professional Hvac

    • The coil refreezes after you've already thawed it and replaced the air filter.
    • You suspect a refrigerant leak, which can be indicated by hissing sounds or oily residue on the copper lines.
    • The blower motor is not running when you switch the thermostat fan to 'ON'.
    • You are not comfortable working around the electrical and mechanical components of your HVAC system.

    Prevention Tips

    • Regularly replace or clean your air filter every 1-3 months, or even monthly during heavy use.
    • Schedule annual professional AC maintenance to have coils cleaned and refrigerant levels checked.
    • Keep all supply and return vents clear of obstructions like furniture, rugs, and drapes.
    • Ensure the area around your indoor and outdoor units is clear to maintain good airflow.
    Frozen AC Evaporator Coil (Troubleshooting & Fixes) professional repair detail
    Professional key fob repair and programming
